B-Nimis MC-I/O CAN

Berghof Automation: Extension module B-Nimis MC-I/O CAN

● Dimensions: 25 x 124 x 83mm

● Mounting: Rail mounting NS 35/7,5 EN 50022

● Certification: CE (EN 61131-2) / cULus (UL 61010-2-201)

● Development environment: CODESYS V3 (IEC61131-3)

Protocols

● EtherCAT Slave

Communication interfaces

● 1x Can

EMC, protection class

● Protection type: IP20

● Protection class: III

Vibration resistance

● Vibration: Sinusodial (EN 60068-2-6) test: Fc; 10 … 150 Hz, 1 G (operation mode)

● Schock resistance: 15 G (approx. 150 m/s2), 10 ms duration, half-sine (EN 60068-2-27) test: Ea

Plug connection

● Plug MC-IO 18-polig (available separately, see accessories)
