ECCO X 012 Laser-Class 3R Option 1

3D-Laser Scanner, SmartRay, ECCO X 012 Option 1, Laser Class 3R

● compact industrial case for high-speed 3D scans

● Typ. Field of View: 12 mm

● Measurement Range: 6 mm

● Typ. Scanrate: up to 40 kHz

● Option 1: Connector position (see product image)

Resolution

● Typ. vertical Resolution: 0.3 – 0.4 µm

● Typ. laterale Resolution: 2.7 – 3.2 µm

● Maximal Points / 3D-Profile: 4096

Interface / Laserclass

● Interface: Gigabit Ethernet (1 Gbit/sec)

● Laserclass: 3R

● Laser wavelength: 450 nm (blue)

●  ❗ WARNING: Operate the device only with suitable laser safety glasses or protective enclosure.

Inputs / Outputs

● Inputs: 2 (5-24VDC)

● Input: Quadratur Encoder (AB-Channel, RS422 standard)

● Synchronous input for multi-sensor operation

● Outputs: 2 (24VDC, max 20mA)

Trigger

● Start-Trigger (support inputs 1-2)

● Data-Trigger quadratur Encoder (max. 1MHz)

● Data-Trigger Support Input 2 (max Datatrigger 10kHz)

Protection /Housing

● IP67

Operation Power

● 24 VDC, ± 15 % ripple | 8.5 W
